IRPLCFL5E
the lamp during preheat and startup while increasing the preheat current. LRES may
need to be decreased to maintain the same power and the same frequency.
3.2) If the IC works at a frequency greater than fmin, increase CRES or LRES to decrease the
resonant frequency avoiding hard-switching, or, decrease the value of the snubber
capacitor CSNUB (a CSNUB minimum value of 680pF is suggested to make
sure VCC stays above the UVLO-).
3.3) If VCC drops, increase the value of CSNUB or CVCC
4) Adjust the value of RFMIN to have the right power on the lamp (increase RFMIN to
increase power or decrease RFMIN to decrease power) and the value of CVCO to set
the correct preheat time (increase CVCO to increase the preheat time and decrease
CVCO to decrease the preheat time).
5) Test the ballast over the entire input range and make sure that the frequency does not
change dramatically in your working range. Select the value of RSUPPLY to have startup
at the correct AC line voltage. Increase the value of RSUPPLY to start the IC at higher
AC voltages and decrease the value of RSUPPLY to start the IC at lower AC voltages.
6)
Test your lamp life (number of starts). A good design should guarantee at least 5,000
starts. To increase the number of starts, increase CRES or the preheat time (CVCO).
WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245 Tel: (310) 252-7105
http://www.irf.com/ Data and specifications subject to change without notice. 5/14/2004
